抓斗吊钩两用桥式起重机是在散料场所使用较多的一种双梁桥式起重机,型号为QN,QN型抓斗吊钩两用桥式起重机既可使用抓斗抓取各类散状物料,也可利用吊钩吊取其他重物。小编为大家介绍下5/5吨、10/10吨、16/16吨抓斗吊钩两用桥式起重机的技术参数。
![抓斗、吊钩两用桥式起重机](https://cdn.qizhongji.com/wp-content/uploads/2021/10/2021102211563113.png)
抓斗、吊钩两用桥式起重机起重机结构图:
![抓斗吊钩两用桥式起重机结构图](https://cdn.qizhongji.com/wp-content/uploads/2021/10/2021102211563113.png)
5/5吨10/10吨16/16吨抓斗、吊钩两用桥式起重机技术参数表
起重量 Lifting Weight | t | 5/5 | 10/10 | 16/16 | ||||||||||||||||||||
跨度 Span m | 10.5 | 13.5 | 16.5 | 19.5 | 22.5 | 25.5 | 28.5 | 31.5 | 10.5 | 13.5 | 16.5 | 19.5 | 22.5 | 25.5 | 28.5 | 31.5 | 19.5 | 22.5 | 25.5 | 28.5 | 31.5 | |||
最大起升高度Max Lifting Height | m | 20/22 | 18/22 | 22 | ||||||||||||||||||||
工作级别 Working class | A6 | |||||||||||||||||||||||
速度 Speed | 起升 Lift | m/min | 40.1/15.4 | 40.26/14.5 | 41.8/13 | |||||||||||||||||||
小车运行 handcar travel | 44.6 | 45.6 | 43.2 | |||||||||||||||||||||
大车运行 crat travel | 93.7 | 113 | 112.5 | 101 | 98 | 87.3 | ||||||||||||||||||
电机 Motor | 起升 Lift | 抓斗 Grab | Type/ kw | YZR225-8/22 | YZR208S-10/37 | YZR315M-10/75 | ||||||||||||||||||
吊钩 Hook | YZR180L-6/15 | YZR225M-8/22 | YZR250M1-6/37 | |||||||||||||||||||||
小车运行 handcar travel | YZR132M2-6/3.7 | YZR160M1-6/5.5 | YZR160M2-6/7.5 | |||||||||||||||||||||
大车运行 crat travel | YZR160M2-6/7.5×2 | YZR160L-6/11×2 | YZR160M2-6/7.5×2 | YZR160L-6/11×2 | YZR200L-8/15×2 | |||||||||||||||||||
主要尺寸 (mm) Main Size | B | 6355 | 6485 | 7090 | 6385 | 6485 | 7145 | 6870 | 7000 | |||||||||||||||
Ba | 4000 | 4100 | 5000 | 4000 | 4100 | 5000 | 4800 | 5000 | ||||||||||||||||
BX | 3550 | 4420 | 5250 | |||||||||||||||||||||
b | 230 | 230 | 250 | 250 | 300 | |||||||||||||||||||
LX | 2000±2 | 2000±2 | 2500 | |||||||||||||||||||||
H | 1893 | 1943 | 2095 | 2185 | 2418 | 2548 | ||||||||||||||||||
H1 | 2548 | 2608 | 2708 | 2858 | 3008 | 3108 | 3258 | 3408 | 2550 | 2610 | 2760 | 2770 | 2920 | 3070 | 3220 | 3320 | 2924 | 2944 | 3094 | 3194 | 3294 | |||
H2 | 735 | 785 | 785 | 890 | 880 | 1010 | ||||||||||||||||||
S1 | 1520 | 1700(1800) | 2175(2275) | |||||||||||||||||||||
S2 | 1500 | 1500(1600) | 1575(1675) | |||||||||||||||||||||
F | 128 | 228 | 328 | 478 | 628 | 728 | 878 | 1028 | 130 | 230 | 380 | 380 | 530 | 680 | 830 | 930 | 544 | 564 | 714 | 814 | 914 | |||
h | 2020 | 2550 | 2795 | |||||||||||||||||||||
重量 Weight | 小车 Handcart | t | 7.6(8.4) | 11.5(12.5) | 19.9(21) | |||||||||||||||||||
总重量Total Weight | 室内Indoor | 22.7 | 24.4 | 26.4 | 29.2 | 32 | 36.8 | 40.5 | 43.8 | 26.5 | 28.4 | 31.1 | 35 | 38.4 | 43 | 46.8 | 50.4 | 56.4 | 60.3 | 64.8 | 67.7 | 72 | ||
室外Outdoor | 23.7 | 25.3 | 27.3 | 30.1 | 32.9 | 37.7 | 41.4 | 44.7 | 27.4 | 29.3 | 32.5 | 35.8 | 39.3 | 43.9 | 47.8 | 51.2 | 57.6 | 61.7 | 66.2 | 69.1 | 73.5 | |||
最大轮压 Max.Wheel Pressure | 室内Indoor | 10.2 | 10.9 | 11.6 | 12.7 | 13.1 | 14.7 | 15.8 | 16.8 | 14.8 | 15.9 | 17.3 | 18.6 | 19.6 | 20.9 | 21.9 | 22.9 | 27.3 | 28.4 | 30.6 | 31.7 | 32.1 | ||
室外Outdoor | 10.6 | 11.3 | 12 | 13.1 | 13.4 | 15.1 | 16.1 | 17.1 | 15.2 | 16.3 | 17.7 | 19 | 19.9 | 21.3 | 22.3 | 23.3 | 27.9 | 28.8 | 30.9 | 32 | 32.4 |
抓斗 Grab | 型号Model | u | 113 | 109 | 110 | 105 | 106 | 101 | 102 | 127 | 123 | 124 | 119 | 120 | 115 | 116 | 141 | 137 | 138 | 133 | 134 | 129 | 130 |
类型Type | 轻型 Light | 中型 Medium | 重型 Heauy | 超重型 spuer heavy | 轻型 Light | 中型 Medium | 重型 Heauy | 超重型 spuer heavy | 轻型 Light | 中型 Medium | 重型 Heauy | 超重型 spuer heavy | |||||||||||
容积Volume | m3 | 2.5 | 1.5 | 1 | 0.75 | 5 | 3 | 2 | 1.5 | 8 | 4.8 | 3.2 | 2.5 | ||||||||||
容重Density | t/m3 | ≤1 | >1-1.7 | >1.7-2.5 | >2.5-3.3 | ≤1 | >1-1.7 | >1.7-2.5 | >2.5-3.3 | ≤1 | >1-1.7 | >1.7-2.5 | >2.5-3.3 | ||||||||||
自重 Dead Weight | kg | 2633 | 2549 | 2615 | 2506 | 2568 | 2479 | 2546 | 4800 | 4803 | 4866 | 4850 | 4913 | 4730 | 4793 | 7841 | 7993 | 8143 | 8008 | 8159 | 8155 | 8305 | |
主要尺寸(mm)MainSize | Ba | 1634 | 1444 | 1238 | 1160 | 2060 | 1764 | 1528 | 1416 | 2350 | 2078 | 1792 | 1628 | ||||||||||
Bb | 2425 | 2175 | 2025 | 1875 | 2970 | 2670 | 2470 | 2230 | 3515 | 3135 | 2915 | 2665 | |||||||||||
Bc | 3120 | 2740 | 2900 | 2530 | 2690 | 2340 | 2500 | 3900 | 3430 | 3590 | 3220 | 3380 | 3920 | 3080 | 4380 | 4050 | 4250 | 3750 | 3950 | 3430 | 3630 | ||
Hp | 3135 | 2935 | 3015 | 2835 | 2915 | 2735 | 2815 | 3990 | 3747 | 3827 | 3640 | 3720 | 3490 | 3570 | 4775 | 4605 | 4705 | 4455 | 4455 | 4285 | 4385 | ||
Hb | -3615 | -3385 | -3605 | -3255 | -3475 | -3125 | -3345 | -4560 | -4297 | -4517 | -4125 | -4345 | -3910 | -4130 | 5530 | 5243 | 5483 | 4979 | 5219 | 4811 | 5051 |
荐用钢轨 Steel track | 43kg/m | QU70 □90×90 | ||||||||||||||||||||||
电源 Power Supply | 三相交流3-PhaseA.C.50Hz 380V |
